SimCom SIM800L User Manual

Smart Machine Smart Decision
SIM800L(MT6261)_Hardware Design_V1.01 57 2016-07-07
4 22 ±3 ±4
5 20 ±3 ±4
6 18 ±3 ±4
7 16 ±3 ±4
8 14 ±3 ±4
9
12
±4
±5
10 10 ±4 ±5
11 8 ±4 ±5
12 6 ±4 ±5
13 4 ±4 ±5
14
2
±5
±6
15
0
±5
±6
6.10.2. Module RF Receive Sensitivity
The following table shows the module’s conducted receiving sensitivity, it is tested under static condition.
Table 47: Conducted RF receive sensitivity
Frequency Receive sensitivity
（
Typical
）
Receive sensitivity(Max)
GSM850,EGSM900
< -108dBm
< -106dBm
DCS1800,PCS1900
< -108dBm
< -106dBm
6.10.3. Module Operating Frequencies
The following table shows the module’s operating frequency range; it is followed by the 3GPP TS 05.05
technical specification requirement.
Table 48: Operating frequencies
Frequency
Receive
Transmit
GSM850
869
～
894MHz
824
～
849MHz
EGSM900
925 ～ 960MHz 880 ～ 915MHz
DCS1800
1805 ～ 1880MHz 1710 ～ 1785MHz
PCS1900
1930 ～ 1990MHz 1850 ～ 1910MHz
SIMCOM CONFIDENTIAL FILE

SimCom SIM800L Specifications

General

Brand	SimCom
Model	SIM800L
Category	Recording Equipment
Language	English
