SIM800L(MT6261)_Hardware Design_V1.01 59 2016-07-07
7.3. The Moisture Sensitivity Level
The moisture sensitivity level of SIM800L module is 3. The modules should be mounted within 168 hours after
unpacking in the environmental conditions of temperature <30 ℃
a n d re la tiv
necessary to bake the module if the above conditions are not met:
Table 49: Moisture sensitivity level and floor life
Moisture Sensitivity Level
(MSL)
Floor Life (out of bag) at factory ambient≤30°C/60% RH or as stated
1 Unlimited at ≦30℃/85% R H
2
1 year
2a 4 weeks
3
168 hours
4 72 hours
5 48 hours
5a 24 hours
6
Mandatory bake before use. After bake, it must be reflowed within the time limit
specified on the label.
Note: For product handling, storage, processing, IPC / JEDEC J-STD-033 must be followed.
7.4. Baking Requirements
SIM800L modules are vacuum packaged, and guaranteed for 6 months storage without opening or leakage under
the following conditions: the environment temperature is lower than 40 ℃
, and the air h
If the condition meets one of the following ones shown below, the modules should be baked sufficiently before
re-flow soldering, and the baking condition is shown in below table; otherwise the module will be at the risk of
permanent damage during re-flow soldering.
 If the vacuum package is broken or leakage;

If the vacuum package is opened after 6 months since it’s been packed;

If the vacuum package is opened within 6 months but out of its Floor Life at factory
ambient ≦30℃/60% R H or as stated
.
Table 50: Baking requirements
Baking temperature Moisture Time
40 ℃±5 ℃ <5% 192 hours
120
℃±5 ℃
<5%
6 hours
Note: Care should be taken if that plastic tray is not heat-resistant, the modules should be taken out for preheating, otherwise the
tray may be damaged by high-temperature heating.
