SimCom SIM900 Reference Design Guide

SIM900 Reference Design Guide Notes
SIM900_AN_Reference Design Guide_V1.01 01.27.2010
11
9) RF trace between SMT module RF pad with the RF test connector, RF trace between RF
test connector with the antenna matching circuit, RF trace between the antenna matching
circuit with the antenna feed PAD all should be controlled to 50 Ohm
10) All layers under the antenna feed pad should be copper keep out.
11) Do not layout RF trace in orthogonal
12) When layout surface Microstrip Transmission Line or offset Stripline Transmission
Line , 3W rule should be followed, that means the distance between reference GND with
RF trace should three times more than the width of RF trace.

SimCom SIM900 Specifications

General

Brand	SimCom
Model	SIM900
Category	Modem
Language	English
