Capacity 50L 80L 100L
Code 8115610 8115611 8115612
Installation
Vertical-Horizontal
SPECIFICATIONS
Power (W) 1600 1600 1600
Q (annual consumption) (kWh) 1428 1432 1419
L (noise level) 15dB 15dB 15dB
∏wh 36% 36% 36.2%
Equivalent capacity at 40°C (L) 69 110 154
Class C C C
Load profile M M M
Nominal voltage (V) 220-240 220-240 220-240
Frequency (HZ) 50/60 50/60 50/60
Maximum pressure (MPa) 0.75 0.75 0.75
Maximum temperature (°C) 75 75 75
Low temperature (°C) 30 30 30
Degree of electrical protection IP24 IP24 IP24
Nominal current (A) 7 7 7
Wall installation Wall Wall Wall
Weight when empty (KG) 19.5 26.5 31.5
WARRANTY
The 2-year warranty will be valid provided that the magnesium anode is inspected or
replaced once a year.
8
TECHNICAL DATA
