SRM9030 ~ PMR Mobile Radio User Guide
© ComGroup Australia 2010 27 TNM-U-E-0003 Issue 4a
7.11 GO TO CHAN A, B, C, D
Selects predefined Channel A, B, C or D, and returns on the second press.
The Defined Channel is redefined if held for approximately 2 seconds.
7.12 SPECIAL ENC 1…8
Sends Special Encode 1, 2, … 8
7.13 ALARM
Put the mobile into Alarm mode.
7.14 REPEATER DEFEAT
Allows the radio to transmit on the reverse frequency on a Repeater Channel.
When the button is pressed again (or the Channel is changed) the transmit
frequency reverts to the original setting.
7.15 LOW POWER
Forces the radio to low power.
Pressing again puts the radio back to the power level defined for the current
channel. This is not affected by Channel changes.
7.16 HANDSFREE (VOX)
Toggles the VOX function for the Handsfree Microphone.
7.17 DTMF MODE
This function places the numeric keypad into DTMF mode, refer to Section 5.7.
7.18 SCRAMBLER ON/OFF
If enabled by the Field Programmer, this function toggles the state of the
speech scrambler. When active, there will be a short audible tone at the start of
PTT to inform the user of the scrambler activation. Each time the key is
pressed, the display will show “On” and “Off”.
