Annex I: Prototype Installation
Contents
1. Introduction 128
2. Standard Connection 129
3. Physical addressing of channels 130
4. Programming in the console 131
4.1 Access to installer mode 131
4.1.1 Checking the Installation, Test Screen 132
4.2 Creation of channels 133
4.3 Configuring the Start screen 136
4.4 Configuring the bush button input 137
1. Introduction
As an extension of the user manual below we include an installation and programming guide for a basic
installation.
For the installation to be appropriate, we have configured an installation with some of the elements and devices
that range from RGB control to fluorescence ballasts and halogens.
The prototype installation includes:
· Touch LightManager Console
· Touch LightKeypad Button Box
· Led RGB flex strip
· DMX-PWM converter for RGB strip
· Flex Strip led source for the DMX-PWM converter
· Fluorescence ballast
· DMX-DALI converter for control of the ballast
· Halogen bulb
· Push button
· Digital signal converter
As we can see below, the connection of the elements in their data part is done with a screened FTP data cable.
The devices are powered by means of 230V phase and neutral cable except the DMX-PWM converter, which
works with 12-24V.
The devices are associated in series, such that the last device will be associated with a resistor of 120ohms
between the two data terminals.
We can therefore see how the grid cable is connected between the devices.
