3. Physical addressing of channels
Associate an address with each device, taking into account the elements and converters that must have
addressing higher than 20 to avoid interference.
Therefore:
Device Address Switch pins to ON
Electronic transformer regu-
lator module
1
Digital input module 2
Button box Automatic Doesn’t have ND switch
DMX-PWM converter 21
DMX-DALI converter 31
