4.2 Creation of channels
Automatic devices
We first proceed to register automatically.
The automatic search screen will appear followed by the
acknowledged channels.
As we can see, the console has acknowledged channels 0-10
001 DIG 002 and BOT 000, which means it has
acknowledged the Scena modules that are not protocol
converters.
To acknowledge the protocol converter devices, a manual
search will be performed.
DMX-PWM converter
To create channels manually such as the DMX-PWM
converter and the DMX-DALI converter, we select add
channels manually and we will have to configure the following
options:
· Type selection
· Channel name
· DMX address (the one selected in the switch).
