Simoniz VE07 - 3 E Xploded V Iew; 4 Arts ist

6
3. exploded VIew
Exploded View / Parts List
4. parts lIst
Item # Part Name Qty. Part #
*A Hand crank 1
VE01-002-0035
B Cord bracket 1
VE06-030-0001
C Gun holster 1
VE06-030-0002
D
Foam blaster
1
XE20-060-0000
F
3-in-1 wand
1
VE07-020-0090
Pre-attached on the manual
Pre-attached on the machine
Item # Part Name Qty. Part #
G Gun assembly 1
XE03-020-0090
I 1
n/a 1
n/a Water lter 1
*Hand crank comes pre-attached on the machine.
I
G
F
A
B
C
D
High-pressure
hose
VE07-000-0003
Cleaning
needle
