2100 PSI Electric Pressure Washer
039-8065-8
Congratulations on the purchase of your new pressure washer. In order
to ensure you have the best possible experience, please read through the
following instructions. If you require any help, please contact the customer
service department at:
1-866-474-6664
Contact us for assistance; we’re here to help.
Use and Care Guide
Model no. XE29
Version no. 00

Table of Contents

Questions and Answers

  • D
    David HatfieldAug 17, 2025
    Why won't my Simoniz Platinum motor start?
    • J
      john04Aug 17, 2025
      If the motor of your Simoniz Pressure Washer doesn't start, there could be several reasons. First, ensure the device is in ON mode by pushing the ON/OFF button. Then, check if the power cord is properly plugged in. Also, the extension cord might be too long, not the proper gauge, or damaged; replace it with a 25’ (7.6 m) or 50’ (15 m) 14/3 gauge cord. The power outlet might not supply enough power, so try a different outlet. Finally, the pressure washer circuit breaker might have tripped; allow the device to cool, and then restart it.
  • S
    Sherry BartonAug 19, 2025
    Why does my Simoniz Pressure Washer motor hum but not run?
    • S
      Scott AtkinsonAug 20, 2025
      If your Simoniz Pressure Washer motor hums but fails to run, consider these potential causes: The supply voltage may be below the minimum; verify that only the pressure washer is running on this circuit. The system might have residual pressure; turn the device to OFF mode, pull the trigger on the spray gun to release pressure, and then turn the device back ON. Voltage loss due to the extension cord could also be a factor; unplug any extension cords and plug the unit directly into the outlet. There might be residual friction among components; disconnect the water supply and power ON for 2 to 3 seconds, repeating this procedure a few times until the motor starts.
  • T
    Tabitha JonesAug 22, 2025
    How to fix detergent not working on Simoniz Pressure Washer?
    • M
      Mary PriceAug 22, 2025
      If the detergent is not working on your Simoniz Pressure Washer, consider these possible causes: the detergent container might be empty, so add more detergent. Check the detergent bottle or suction tube connections to ensure they are properly connected. If the detergent is too thick, dilute it. Also, the filter on the detergent suction tube might be clogged; run warm water through it to remove any build-up. A damaged or clogged detergent suction tube can also be the reason; remove any obstruction or replace the tube. Finally, make sure that the ON/OFF button is in the ON mode.
  • N
    Nathan PorterAug 26, 2025
    How to fix a leaking garden hose connection on Simoniz Platinum Pressure Washer?
    • L
      Leslie DayAug 26, 2025
      If the garden hose connection on your Simoniz Pressure Washer is leaking, it could be due to loose fittings; tighten them. Also, check for a missing or worn rubber washer and insert a new one if necessary.
  • J
    Jodi RichardsonAug 28, 2025
    What to do if my Simoniz Pressure Washer doesn't reach high pressure?
    • C
      Courtney MillerAug 28, 2025
      If your Simoniz Pressure Washer isn't reaching high pressures, several factors could be the cause. The garden hose might be too small; replace it with a 1” (25 mm) or 5/8” (16 mm) garden hose. A restricted water supply could also be the issue; check the garden hose for kinks, leaks, or blockages. Ensure you have enough water supply by fully opening the water source. A clogged water inlet filter can also reduce pressure; remove the filter and rinse it with warm water. Lastly, the power nozzle might be in the low-pressure position; replace it with the desired high-pressure tip.
  • S
    smithkathleenAug 30, 2025
    Why does the output pressure fluctuate on my Simoniz Platinum Pressure Washer?
    • C
      Carolyn WallerAug 31, 2025
      If the output pressure of your Simoniz Pressure Washer fluctuates, it could be due to several reasons. Ensure there's enough inlet water supply by turning the faucet on fully and checking the garden hose for kinks, leaks, or blockages. The pump might be sucking air; check if all hoses and fittings are airtight, then turn the device OFF and purge the pump by pulling the trigger on the spray gun until a steady flow of water emerges through the nozzle. A clogged water inlet filter can also cause pressure fluctuations; remove the filter and rinse it with warm water. Additionally, the discharge nozzle might be obstructed; blow out or remove debris with a fine needle. Finally, the gun, hose, or power nozzle might be calcified; run distilled vinegar through the detergent container.
  • Z
    zrodriguezSep 2, 2025
    Why is the pump on my Simoniz Platinum so noisy?
    • A
      Audrey DominguezSep 2, 2025
      A noisy pump in your Simoniz Pressure Washer can be attributed to a couple of reasons. The pump might be sucking air; check if all hoses and fittings are airtight, then turn the device to OFF mode and purge the pump by pulling the trigger on the spray gun until a steady flow of water emerges through the nozzle. Alternatively, the water filter could be clogged; remove the filter and rinse it with warm water.
  • N
    Natasha ZavalaSep 5, 2025
    Why is no water coming out of the Simoniz Platinum nozzle?
    • R
      Richard WhiteSep 5, 2025
      If no water is coming out of the nozzle of your Simoniz Pressure Washer, the water supply might be OFF; turn on the water supply. Alternatively, there might be a kink in the garden hose; remove the kink.
  • J
    Jason RiggsSep 8, 2025
    Why is my Simoniz Pressure Washer spray wand leaking?
    • J
      Jennifer DownsSep 8, 2025
      If your Simoniz Pressure Washer spray wand, extension, or nozzle is leaking, it could be because the spray nozzle was not properly attached; ensure the quick-connect wand is attached securely and the project dial is clicked in securely. If there is a broken O-ring or plastic insert: Call the Toll-free Hotline.
  • T
    Terry GrossSep 12, 2025
    Why is my Simoniz Platinum Pressure Washer pump leaking water?
    • D
      Diana RobinsonSep 12, 2025
      If your Simoniz Pressure Washer pump is leaking water, ensure all fittings are tight. If the water seals are damaged or worn: Call the Toll-free Hotline.

Summary

IMPORTANT PRECAUTIONS

Safety Warnings

Provides critical safety warnings regarding operation, electrical hazards, and pressure.

Safety Features and Electrical Information

Extension Cords

Details requirements and warnings for using extension cords with the pressure washer.

ASSEMBLY INSTRUCTIONS

Pre-Assembly Procedures

Assembly Steps

Provides a step-by-step guide for assembling the pressure washer components.

OPERATING INSTRUCTIONS

Using the Foam Blaster

Post-Operation Procedures and Warnings

Details shutdown, cleaning, break procedures, and critical operating warnings.

WINTERIZING and Long-Term Storage

Optimum Winterizing Procedure

Quick Winterizing Procedure

CLEANING AND MAINTENANCE

Technical SPECIFICATIONS

TROUBLESHOOTING

Simoniz Platinum Series Specifications

General IconGeneral
Maximum Pressure3200 PSI
Flow Rate2.5 GPM
Engine Displacement196cc
Power SourceGasoline
Hose Length25 ft
Nozzle TypeQuick Connect
Nozzles Included0°, 15°, 25°, 40°, Soap
