5. assembly InstructIons (cont.)
5.4 Assembly Steps (cont.)
G
Connect garden hose to the inlet adaptor.
Assembly Instructions
The spray nozzles on 3-in-1 wand are selected with the
desired spray pattern for the following purposes:
• 0º: For tough spots and grimes
(e.g., concrete surfaces);
• 15º: For medium and heavy duty cleaning
tasks (e.g., driveway);
• 40º: For light duty jobs and to apply
detergent (e.g., stucco walls, glossy
surfaces);
0º
15º
40º
F
