Simplex 100 User Manual

OPTIONAL FEATURES
24
MASTER/ SLAVE - The S100 series clock receives and retransmits Simplex 58th-Minute
corrections in daisy chain configuration.
Note: In the daisy chain configuration, there is a one second delay between each clock in the
chain.
MASTER/ SLAVE - The S100 seies clock receives and retransmits Simplex 58th-Minute
corrections in parallel configuration.
Master
Clock Simplex 100 Simplex 100 Simplex 100
or OUT+ IN+ OUT+ IN+ OUT+ IN+ OUT+
Simplex
100 OUT- IN- OUT- IN- OUT- IN- OUT-
Master
Clock Simplex 100 Simplex 100 Simplex 100
or OUT+ IN+ IN+ IN+
Simplex
100 OUT- IN- IN- IN-
