Simplex 100 - Master Clock Connections

OPTIONAL FEATURES
23
The S100 series clock can operate in the following master clock configurations:
SLAVE - The S100 series clock receives 24 VDC Simplex 58th-Minute corrections from a master
clock.
SLAVE - The S100 series clock receives 115VAC Simplex 58th-Minute corrections from a master
clock
MASTER - The S100 series clock transmits 58th-minute corrections.
OUT + IN +
OUT - IN -
115VAC Simplex IN+ Simplex
Bell/Sync. 100
SYNC. Option IN - Slave
OUT+ IN+
OUT- IN-
Master
Clock
Simplex
100
Slave
Master
Clock
Simplex
100 as
Master
Simplex
100
Slave
