8.4 DIP switch SW4
1. You can enable or disable annunciators using DIP switches SW4-1 and SW4-2.
2. You can connect or disconnect the DACT using DIP switch SW4-3.
3. You can enable or disable the city circuit module using DIP switch SW4-4.
4. You can enable or disable the Active Status Reminder feature using DIP switch SW4-5.
5. You can turn the AHJ Reset feature on or off using DIP SW4-6.
6. You can enable or disable the Depleted Battery Cutout feature using DIP switch SW4-7.
7. You can select the Warm start or Cold start power cycle using DIP switch SW4-8.
8. See the following tables for switch setting.
Table 26: DIP switch SW4-1 settings
SW4-1 Description
0 Annunciator 1 is disabled (Default)
1 Annunciator is enabled
Table 27: DIP switch SW4-2 settings
SW4-2 Description
0 Annunciator 2 is disabled (default)
1 Annunciator is enabled
Table 28: DIP switch SW4-3 settings
SW4-3 Description
0 DACT is connected (default)
1 DACT is disconnected
Table 29: DIP switch SW4-4 settings
SW4-4 Description
0 City circuit module is disabled (default)
1 City circuit module is enabled
Table 30: DIP switch SW4-5 settings
SW4-5 Description
0 Active Status Reminder feature is enabled (default)
1 Active Status Reminder feature is disabled
Table 31: DIP switch SW4-6 settings
SW4-6 Description
0 AHJ Reset feature is off (default)
1 AHJ Reset feature is on
Table 32: DIP switch SW4-7 settings
SW4-7 Description
0 Depleted Battery Cutout feature is disabled (default)
1 Depleted Battery Cutout feature is enabled
Table 33: DIP switch SW4-8 settings
SW4-8 Description
0 Warm start power cycle is selected (default)
1 Cold start power cycle is selected
page 25 579-1403 Rev A
2004 Foundation Series Fire Alarm Control Unit Operation Guide
