9 Appendix A: CID points default values
Table 34: CID points default values
Description CID points Event code
IDC 1 through IDC 4 GRP:01 ID:001 through GRP:01 ID:004 Based on device function type
NAC 1 GRP:01 ID:201 *
Aux relay 1 GRP:01 ID:203 *
Aux relay 2 GRP:01 ID:204 *
Aux relay 3 GRP:01 ID:205 *
AC power GRP:01 ID:207 Trouble 301
Aux power GRP:01 ID:208 Trouble
Positive earth fault GRP:01 ID:209 Trouble 310
Negative earth fault GRP:01 ID:210 Trouble 310
Low battery GRP:01 ID:211 Trouble 302
Battery depleted GRP:01 ID:212 Trouble
Low battery cutout GRP:01 ID:213 Trouble
Charger trouble GRP:01 ID:214 Trouble
Manual test report GRP:01 ID:233 Test 601
DACT phone line 1 trouble GRP:01 ID:233 Trouble 351
DACT phone line 2 trouble GRP:01 ID:234 Trouble 352
6 hr test report GRP:01 ID:235 Test 602
6 hr test report, off normal GRP:01 ID:235 Test 608
Extra card GRP:01 ID:236 Trouble
External comm trouble GRP:01 ID:237 Trouble
Cold start GRP:01 ID:239 Trouble
Warm start GRP:01 ID:240 Trouble
Time and date not set GRP:01 ID:242 Trouble
List overflow GRP:01 ID:244 Trouble
City disconnect GRP:01 ID:245 Trouble
City 1 trouble GRP:01 ID:246 Trouble
City 2 trouble GRP:01 ID:247 Trouble
Control bypass GRP:01 ID:248 Trouble
Elevator bypass GRP:01 ID:249 Trouble
Door bypass GRP:01 ID:250 Trouble
AV tally exceeded GRP:01 ID:251 Trouble
Walk test active GRP:01 ID:252 Trouble
Programming mode GRP:01 ID:255 Trouble
Event queue overflow GRP:01 ID:256 Trouble
