Power Supply Output Details:
RUI Communications controls up to 10 remote devices
at up to 2500 ft (762 m) for single run, or 10,000 ft
(3048 m) total if wiring is Class B and T-tapped; output
is selectable as Class B or Class A
Compatible RUI remote equipment includes:
4606-9202 and 4606-9205 Color Touchscreen
Annunciators (up to 6 total), 4100 Series 24 I/O and
LED/Switch modules, 4602 Series LED/Switch and I/O
Annunciator modules, including 4602-9101 Status
Command Units (SCU), and 4602-9102 Remote
Command Units (RCU)
IDNet+ SLC Output provides electrically isolated
Class B or Class A communication; standard capacity is
up to 100 addressable points with expansion for up to
250 points using up to two 4007-9803 IDNet+ Loop
Expansion Modules (as described on page 4)
Battery Charger is dual rate, temperature
compensated, and charges up to 18 Ah sealed lead-
acid batteries in the battery compartment, and charges
up to 33 Ah batteries in an external cabinet
Power Supply Output Details (Continued):
Battery and Charger Monitoring includes battery
charger status and low or depleted battery conditions;
status information provided to the master controller
includes analog values for: battery voltage, charger
voltage and current, actual system voltage and current,
and IDNAC SLC current
Low Battery Voltage Cutout is selectable when
required (required for ULC listing applications)
4 A Output Rating. This includes current for: IDNAC
controlled notification appliances; IDNet devices;
module currents; and auxiliary output current (battery
charging, CPU, and power supply current are not
subtracted from the 4 A)
2 A Auxiliary Output (AUX/SNAC) can be selected
either as resettable auxiliary power of 2 A @ 24 VDC,
or selected to be a simple NAC (SNAC) for sounder
base power, 4-wire detector power, or door holder
power
Model* Color Description
Supv. Alarm
4007-9201(BA) Red
4007ES with a 3 A, Class B, IDNAC SLC for up to 127 addressable notification
appliances, and 4 A output power supply/battery charger; includes IDNet+
communications for 100 addressable points
Note: Add optional module and other currents separately for battery calculations; base
panel current does not subtract from the 4 A power available for optional modules and
external loads
180 mA 185 mA
4007-9202(BA) Platinum
* Models with (BA) are available assembled in the USA by adding the suffix “BA”.
6 S4007-0002-6 11/2015
Factory
Programming
Options
Model Description
4007-8810 Factory Programming (select)
4007-0831 Custom Labels and Programming (requires 4007-8810)
Field Installed Optional Modules (refer to diagram on page 8 for module locations)
Model Description Supv. Alarm
4007-9801
Eight Point Zone/Relay Module; each point is selectable as an IDC input or Relay output, Class A
IDCs require 2 points (one out and one return); select up to 4 maximum; current shown is for 8 Class
B IDCs with 4 in alarm, detector current is added separately (refer to 4007ES Hybrid data sheet
S4007-0001 for additional information)
83 mA
max
350 mA
max
4007-9802
25 VDC Regulator Module; 2 A maximum output; use to power Zone/Relay
modules connected to initiating devices requiring nominal 25 VDC voltage; refer to
technical publication 579-832, 2-Wire Detector Compatibility Chart for application
details
with 1 module 190 mA 445 mA
with 2 modules 290 mA 801 mA
with 3 modules 390 mA 1156 mA
4007-9803
IDNet+ Loop Expansion Module; provides an additional isolated loop with short circuit isolation to
the existing IDNet+ channel, also provides an additional 75 addressable points to the IDNet+ channel
capacity, maximum of two
NA NA
4007-9804
Dual Class A IDNAC Isolator (DCAI); converts a single Class B IDNAC SLC input to two Class A or
two Class B SLC outputs; provides short circuit isolation between each Class A or B output circuit;
requires one IDNAC address; the total current remains controlled by the Class B input source SLC at
3 A maximum
8.3 mA 18.5 mA
4007-9805
Panel Mounted 48 LED Status Annunciator Module; provides 24 Yellow LEDs,
20 Red LEDs, and 4 Red/Green LEDs that are programmable for up to 24 IDC zones of
alarm and trouble annunciation, or as required for custom annunciation requirements
no LEDs on 10 mA 10 mA
with
LEDs on
1.75 mA per LED,
105 mA max
4007-9806
SDACT Module for Point or Event Reporting; order 2080-9047 connection cables as required (see
cable details under accessories)
30 mA 40 mA
4007-9807 City Circuit Module with Disconnect Switch 20 mA 36 mA
4007-9808 City Circuit Module without Disconnect Switch 20 mA 36 mA
4007-9809 Relay Module; relays for Alarm, Supervisory, and Trouble; rated 2 A resistive @ 32 VDC 15 mA 37 mA
continued on next page
Module and Accessories Selection Information
Power Supply Output and Zone/Relay Module Details
Product Selection
