Power Supply Output Details:
RUI Communications controls up to 10 remote devices
at up to 2500 ft (762 m) for single run, or 10,000 ft
(3048 m) total if wiring is Class B and T-tapped;
selectable as Class B or Class A
Compatible RUI remote equipment includes:
4606-9202 and 4606-9205 Color Touchscreen
Annunciators (up to 6 total), 4100 Series 24 I/O and
LED/Switch modules, 4602 Series LED/Switch and I/O
Annunciator modules, including 4602-9101 Status
Command Units (SCU), and 4602-9102 Remote
Command Units (RCU)
IDNet+ SLC Output provides electrically isolated
Class B or Class A communication; standard capacity is
up to 100 addressable points with expansion for up to
250 points using up to two 4007-9803 IDNet+ Loop
Expansion Modules (as described on page 4)
6 A Output Rating. This includes current for: special
application notification appliances; IDNet devices;
module currents; and auxiliary output current (battery
charging, CPU, and power supply current does not
subtract from the 6 A); when NACs are controlling
Regulated 24 DC Appliances, total NAC current
available is 3 A
Four on-board Class B/Class A NACs, rated 3 A each
for Special Application appliances; selectable for
SmartSync horn and strobe control, or strobe
synchronization; rated 2 A each for Regulated 24 DC
appliances
Power Supply Output Details (Continued):
NAC end-of-line (EOL) resistor values are selectable as:
10 kΩ, 3.9 kΩ, 4.7 kΩ, 5.1 kΩ, 5.6 kΩ, or 15 kΩ
Battery Charger is dual rate, temperature compensated,
and charges up to 18 Ah sealed lead-acid batteries
mounted in the battery compartment, and charges up to
33 Ah batteries mounted in an external cabinet
Battery and Charger Monitoring includes battery
charger status and low or depleted battery conditions;
status information provided to the master controller
includes analog values for: battery voltage, charger
voltage and current, actual system voltage and current,
and NAC current
Low Battery Voltage Cutout is selectable when
required (required for ULC listing applications)
2 A Auxiliary Output (AUX/SNAC) can be selected either
as resettable auxiliary power of 2 A @ 24 VDC, or
selected to be a simple NAC (SNAC) for sounder base
power, 4-wire detector power, or door holder power
Zone/Relay Module Details:
Select as IDC or Relay; configure up to 8, Class B
IDCs, or up to 4, Class A IDCs; or up to 8, Relay outputs
rated 2 A resistive @ 30 VDC (N.O. or N.C.); or
combinations of IDCs and Relays; each zone is
separately configurable as an IDC or Relay output
IDC Support. Each IDC supports up to 30, two-wire
devices
IDC EOL resistor values are selectable as: 3.3 kΩ,
2 kΩ, 2.2 kΩ, 3.4 kΩ, 3.9 kΩ, 4.7 kΩ, 5.1 kΩ, 5.6 kΩ,
6.34/6.8 kΩ, and 3.6 kΩ + 1.1 kΩ; see instructions for
more details
5 S4007-0001-10 1/2017
Factory
Programming
Options
Model Description
4007-8810 Factory Programming (select)
4007-0831 Custom Labels and Programming (requires 4007-8810)
Field Installed Optional Modules (refer to diagram on page 7 for module locations)
Model Description Supv. Alarm
4007-9801
Eight Point Zone/Relay Module, each point is selectable as an IDC input or Relay output, Class A IDCs
require 2 points (one out and one return); one module is included as standard, select up to 3 additional;
current shown is for 8 Class B IDCs with 4 in alarm, detector current is added separately
83 mA
max
351 mA
max
4007-9802
25 VDC Regulator Module; 2 A maximum output; use to power Zone/Relay modules
connected to initiating devices requiring nominal 25 VDC voltage; refer to technical
publication 579-832, 2-Wire Detector Compatibility Chart for application details
with 1 module 190 mA 445 mA
with 2 modules 290 mA 801 mA
with 3 modules 390 mA 1156 mA
4007-9803
IDNet+ Loop Expansion Module; provides an additional isolated loop with short circuit isolation to the
existing IDNet+ channel, also provides an additional 75 addressable points to the IDNet+ channel
capacity, maximum of two
NA NA
4007-9805
Panel Mounted 48 LED Status Annunciator Module; provides 24 Yellow LEDs, 20 Red
LEDs, and 4 Red/Green LEDs that are programmable for up to 24 IDC zones of alarm
and trouble annunciation, or as required for custom annunciation requirements
no LEDs on 10 mA 10 mA
with
LEDs on
1.75 mA per LED,
105 mA max
4007-9806
SDACT Module for Point or Event Reporting; order 2080-9047 connection cables as required (see cable
details under accessories)
30 mA 40 mA
4007-9807 City Circuit Module with Disconnect Switch 20 mA 36 mA
4007-9808 City Circuit Module without Disconnect Switch 20 mA 36 mA
4007-9809 Relay Module; relays for Alarm, Supervisory, and Trouble; rated 2 A resistive @ 32 VDC 15 mA 37 mA
4007-9812
Dual RS-232 Interface Module; Compatible with Simplex remote printer, PC annunciator or third party
interface (two ports/connections maximum)
60 mA 60 mA
Model* Color Description Supv. Alarm
4007-9101(BA) Red
4007ES Hybrid with 4 conventional 3 A NACs and a 6 A output power supply/battery
charger; includes IDNet+ communications for 100 addressable points and 1, 4007-9801
Zone/Relay module; Note: Add optional module and other currents separately for battery
calculations; base panel current does not subtract from the 6 A power available for
optional modules and external loads
145 mA 190 mA
4007-9102(BA) Platinum
* Models with (BA) are available assembled in the USA by adding the suffix “BA”.
