Expansion Power Supply (EPS) Installation Instructions
Mounting
Mount the EPS to the main annunciation cabinet as shown
in the figure below
Figure 2 Mounting the EPS
Fasten the EPS to the cabinet with
two slotted torx screws (441-002).
EPS
MAIN
CABINET
Screwholes
