Expansion Power Supply (EPS) Installation Instructions
NAC ratings
The panel is rated Special Application for 2 A maximum
per NAC with Simplex 4901 and 4906 TrueAlert Multi-
Candela Notification Appliances.
For all other UL Listed Notification Appliances, NACs are
rated Regulated 24 VDC at 1.5 A maximum each.
Maximum allowed strobe load on either the main or
expansion power supply is 1.35 A. The balance of the 3 A
capacity can be auxiliary loads or audible notification
appliances.
Synchronization of strobes across all NACs in a system is
UL Listed for the Simplex models noted in the table
below. See the table below for maximum number allowed
of each model appliance per NAC.
All other regulated 24 VDC synchronized notification
appliances require the use of their associated Listed
external synchronization module. Notification Circuit
rating is 1.5 A maximum, 1.35 A maximum strobe load
per power supply.
Table 1 NAC Ratings
15Cd 30Cd 75Cd 110Cd
4906-
Rated
Current
Max. # per
NAC
Rated
Current
Max. #
per NAC
Rated
Current
Max. # per
NAC
Rated
Current
Max. # per
NAC
9101 0.060 33 0.094 21 0.186 10 0.252 7
9102 0.075 26 0.125 16 0.233 8 0.316 6
9103 0.060 33 0.094 21 0.186 10 0.252 7
9104 0.075 26 0.125 16 0.233 8 0.316 6
9127 0.075 26 0.116 17 0.221 9 0.285 7
9128 0.086 23 0.132 15 0.250 8 0.320 6
9129 0.075 26 0.116 17 0.221 9 0.285 7
9130 0.086 23 0.132 15 0.250 8 0.320 6
9151 0.060 33 0.094 21 0.186 10 0.252 7
9154 0.075 26 0.125 16 0.233 8 0.316 6
9153 0.060 33 0.094 21 0.186 10 0.252 7
