Simplex 4008-9801 - Page 4

4
Expansion Power Supply (EPS) Installation Instructions
Figure 3 Interconnections between the MSB and EPS
J1
+-
P3
EPS
TB4
P6
166-438 DATA FLEX
HARNESS
734-179
734-180
BATTERY HARNESS
AC HARNESS
EPS
TOP BOARD
EPS
BOTTOM BOARD
RED: LEFT ON P13/P14; BOTTOM
BLACK: LEFT ON TB4; RIGHT ON P6
(TINTED AREA = PORTION OF
BOTTOM BOARD OBSCURED
BY TOP OF ASSEMBLY)
REMOVE POWER
FROM AC AND BATTERY
TERMINALS AND FROM
EXPANSION POWER
SUPPLY.
R76
DEPLETED BATTERY
CUTOUT JUMPER
CIRCUIT BREAKER
BEFORE WIRING THE
WHITE: RIGHT ON TB4; LEFT ON P6
BLACK: RIGHT ON P13/P14;
ON P3
TOP ON P3
J3 on 4008
J8 on 4006
DEPLETED BATTERY
CUTOUT JUMPER
R407 on 4008
R313 on 4006
MAIN SYSTEM BOARD
P14 on 4008
P13 on 4006
