Input Current
AC 4 A maximum, 120 VAC @ 60 Hz nominal
Battery 9 A maximum @ 24 VDC (during battery operation)
ESS Power Supply
Output Ratings
Power Supply
Output Rating
6 A output for “Special Application” appliances
Note: The 6 A output rating of the ESS was determined
such that optional module currents, and external device
and appliance currents can be directly added together,
not to exceed 6 A total.
Output switches to
battery backup during
mains AC failure or
brownout conditions
IDNAC SLC Ratings
3 A, regulated 29 VDC during Alarm, 127 addresses,
139 unit loads; DC-DC converter circuit is >92%
efficient over operating range
IDNAC SLC Wiring
Output terminals are rated for 20 to 12 AWG with
duplicate output terminals rated for two wires each,
allowing up to four (4) Class B branch circuit T-taps to
be made in the cabinet; additional T-taps may be made
in external wiring junction cabinets or boxes
Auxiliary Power Tap 2 A maximum, rated 19.1 to 31.1 VDC
Compatible Special Application
Appliances
Simplex TrueAlert ES and TrueAlert addressable notification appliances; contact
your Simplex product representative for compatible appliances
Battery Charger
Rating (sealed
lead acid
batteries)
Battery capacity range
UL listed for battery charging of 6.2 Ah up to 110 Ah; ULC listed for charging up to
50 Ah batteries; batteries above 33 Ah require separate cabinet
Charger characteristics
and performance
Temperature compensated, dual rate, recharges depleted batteries within 48 hours
per UL Standard 864; to 70% capacity in 12 hours per ULC Standard S527
Environmental
Operating Temperature 32° to 120°F (0° to 49° C)
Operating Humidity Up to 93% RH, non-condensing @ 90° F (32° C) maximum
Additional
Technical
Reference
Installation Instructions 579-1150
Operating Instructions 579-969
Subject Data Sheet Subject Data Sheet
4010ES Agent Release Applications and
Accessories
S4010-0005 Network Communications S4100-0056
Agent Release Accessories S2080-0010 Multi-Signal Fiber Optics S4100-0049
Building Network Interface S4100-0061 4602 Series SCU/RCU S4602-0001
SafeLINC Internet Interface S4100-0062 PC Annunciator S4190-0013
Interface to VESDA Air Aspiration Detection
Systems
S4100-0026
Addressable Device Compatibility, IDNet
Communication Sensors and Devices
S4090-0011
Serial DACT (SDACT) S2080-0009 4009 IDNAC Repeater S4009-0004
Fire Alarm Network Overview S4100-0055 4003EC Voice Control Panel S4003-0002
TrueInsight Remote Service S4100-0063 120 VAC Desktop Remote Printer S4190-0011
4606-9102 Remote LCD Annunciator S4606-0002 110 Ah Batteries and Cabinets S2081-0012
Graphic I/O Modules S4100-0005 Remote 110 Ah Battery Chargers and Cabinets S4081-0002
Remote InfoAlarm Command Center S4010-0008 BACpac Ethernet Portal Module S4100-0051
PC Annunciator S4190-0013 Network Physical Bridge S4100-0057
TCP/IP Physical Bridge S4100-0029
TYCO, SIMPLEX, and the product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited. VESDA is a trademark of Xtralis Pty
Ltd. NFPA 72 and National Fire Alarm and Signaling Code are trademarks of the National Fire Protection Association (NFPA). ASHRAE and BACnet are trademarks of
ASHRAE, American Society of Heating, Refrigeration, and Air Conditioning Engineers.
Tyco Fire Protection Products • Westminster, MA • 01441-0001 • USA S4010-0011-5 11/2015
www.simplex-fire.com
©2015TycoFireProtect ionProducts.Allrightsreserved.Allspecificationsandotherinfor mationsho wnwerecurrentasofdocumentrevisiondateandar esubjec ttochangewithoutnotice.
