9 S4010-0011-5 11/2015
Model Description
Card Address
Consumption
Card Address
Allocation
Notes
Control Panels (Select One)
4010-9601
4010-9602
2x40 Display, (1) IDNet 2 Communications Channel, Single Bay
Box
2
4010-9603
4010-9604
4010-9606
2x40 Display, (1) IDNet 2 Communications Channel; 48 Pluggable
LED Module
3
4010-9606 is for
Canada
Panel Option Cards (Select As Required)
4010-9901 Flat VESDA HLI Card 1
4010-9922 Flat Network Card 1
4010-9908 4 Point Flat Aux Relay Module 1
4010-9912 Serial DACT 1
4010-9923 SafeLINC Internet Interface Card 1
4010-9914 Building Network Interface Card 1
4010-9918 Dual RS-232 Module 1
4010-9920 8 Zone Initiating Device Circuit - Class B 1
4010-9921 8 Zone Initiating Device Circuit - Class A 1
Remote Annunciation (Select As Required)
4100-9401 Red Cabinet, English
Remote InfoAlarm Command
Center
2
4100-9403 Platinum Cabinet, English 2
4100-9421 Red Cabinet, French 2 for Canada
4100-9423 Platinum Cabinet, French 2 for Canada
4100-9441
Red Cabinet, with blank
inserts for key labels
2
4100-9443
Platinum Cabinet, with
blank inserts for key labels
2
4606-9102 4010ES RUI LCD Annunciator, English 1
4606-9102BA 4010ES RUI LCD Annunciator, English 1
4606-9102CF 4010ES RUI LCD Annunciator, French 1 for Canada
4602-9101 Status Command Unit (SCU) LED Annunciator 1
4602-9102 Remote Command Unit (RCU) LED Annunciator w/control 1
4602-9150 Graphic I/O RCU/SCU Assembly for custom annunciator panels 1
4602-7101 Graphic I/O RCU/SCU Assembly for custom annunciator panels 1
4602-7001 RCU for cabinet mount 1
4602-6001 SCU for cabinet mount 1
4100-7401 24 Point I/O Graphic Module for custom annunciator panels 1
4100-7402 64/64 LED Switch Controller for custom annunciator panels 1
4100-7403 32 Point LED Driver Module for custom annunciator panels 1
4100-7404 32 Point Switch Input Module for custom annunciator panels 1
Total Card Addresses (Not to Exceed 20) TOTAL
4010ES Card Address Allocation
The 4010ES has a maximum Internal and External Card Address Limit of 20 Card Addresses. Use the Table below to calculate
4010ES card address allocation.
INSTRUCTIONS: Below is a list of 4010ES equipment and the quantity of card addresses they consume
1. For the applicable control panel, write in the Card Address Consumption value in the Card Address Allocation column.
(Note: Only select 1 control panel)
2. For the option cards to be installed on the 4010ES, write in the Card Address Consumption value in the Card Address Allocation column.
3. Total the Card Address Allocation column (total must not exceed 20).
To Next Page
