Simplex 4010 Installation Instructions

6
The suppression release kit requires power and communications connections to
the 4010 SFI/O board. Use Steps 1 through 3 to connect a power and
communications harness from the suppression release kit to the 4010 FACP.
Both harness connectors are keyed for correct connection.
1. Connect the 733-950 (white) harness from P1 of the suppression release kit
to P14 of the SFI/O board.
2. Connect the 733-951 (red) harness from P2 of the suppression release kit to
P13 of the SFI/O board.
3. Neatly dress the wiring behind the 4010 chassis using the holes provided to
tie-wrap the harnesses.
The suppression release kit requires connection to the battery terminals (TB8) on
the 4010 SFI/O board.
x Connect the red battery lead from the suppression release kit to the (+)
terminal of TB8 on the SFI/O.
x Connect the black battery lead from the suppression release kit to the (-)
terminal of TB8 on the SFI/O.
Wiring,
Continued
Communication and Power
Wiring
Battery Wiring
