7
Use the following steps to apply AC and battery power to the 4010 FACP.
1. Connect the appropriate dual AC harness to the bottom of the suppression
release kit first and then to the bottom of the main FACP chassis.
2. Connect the crimped ends of the 733-945 battery harness to the batteries.
Observe polarity (red to +, black to -) when connecting batteries.
WARNING: Battery contains sulfuric acid which can cause severe
burns to the skin and eyes, and can destroy fabrics.
Replace any leaking or damaged battery. If contact is
made with sulfuric acid, immediately flush skin or eyes
with water for 15 minutes and seek immediate medical
attention.
After applying power to the system, use the following list to check the 4010 for
proper operation.
x
Check that the green AC Power LED is ON.
x
Check that all yellow and red LEDs are OFF.
x
Use the Lamp Test procedure in the Operation Chapter of this publication to
verify that all 4010 LEDs and LCD segments work properly.
Power-Up and Checkout
Connect AC and Battery
Power
