10
Table 2. 4098 Two-Wire Duct Detector Compatibility.
DUCT DETECTOR SYSTEM
MAXIMUM QUANTITY OF
DETECTORS PER
INITIATING CIRCUIT
4098-9685 Two-Wire Duct Detector
2120 ET/FADM
2120 FABT/VPBT
2120/4100+ ZAM
4001
4002
4020
4100+/4120/UT
4004/4005
4004/4005 High Current
25
18
20
18
30
30
30
20
30
4098-9688 Two-Wire Duct Detector
with Relay Control
(See Note 1)
4002
4020
4100+/4120/UT
4004/4005 High Current (4098-
9688 not used with 4004 & 4005
Low Current systems)
1
1
1
1
Notes:
1. Relay operation cannot be guaranteed unless it is the only device on that zone.
2. Panel compatibility identification marker is model number of the module or panel.
3. Detector compatibility identification marker is model number found on duct detector label.
4. For detailed interconnection data, see wiring diagrams for specific panels.
Continued on next page
Electrical Specifications, Continued
Two-Wire Duct Detector
Compatibility
