Simplex 4100U - Initiating Device Circuits (Idcs); Relay Modules; General Specifications

6 S4100-0035-2 5/02
Firefighters Telephone and General Audio Options
Model Description Size Supv. In Use
4100-1272
Expansion Telephone Control Module with three Class B telephone NACS;
required when telephone circuits are mounted in transponder;
1 Block 75 mA
329 mA
max.
4100-1273 Telephone Class A Adapter Module; mounts on 4100-1272; no additional current required
4100-2320 Audio Bay-to-Bay Interconnection Harness Kit; order one for each audio bay addition
4100-0637 Audio Box Interconnection Harness Kit; order one for each close-nippled audio cabinet
Initiating Device Circuits (IDCs)
Model Description Size Supv. Alarm
4100-5005 Eight zones, Class B 1 Slot 75 mA 195 mA
4100-5015 Eight zones, Class A 1 Slot 75 mA 195 mA
Addressable Interface Modules
Model Description Size Supv. Alarm
4100-3101 IDNet Module, 250 point capacity With 250 IDNet devices, add
–
200 mA 250 mA
4100-3104 IDNet Module, 127 point capacity With 127 IDNet devices, add
–
102 mA 127 mA
4100-3105 IDNet Module, 64 point capacity With 64 IDNet devices, add
–
51 mA 64 mA
Module size 1 Block
Module without devices
–
75 mA 115 mA
IDNet Modules, Specifications for each capacity
Loading per IDNet device
–
0.8 mA 1 mA
Model Description Size Supv. Alarm
Module size 2 Slots
– –
Module without devices
–
270 mA 290 mA
Loading per MAPNET II device
–
1.7 mA 1.7 mA
4100-3102
MAPNET II Module, 127 point
capacity, add devices separately
Fully loaded module, total
–
470 mA 490 mA
4100-3103
MAPNET II Isolator Module, separates 127 input points into four isolated outputs,
mounts next to 4100-3102 only
1 Slot 50 mA 50 mA
Relay Modules
Model Description Size Supv. Alarm
4100-3201 Four DPDT relays, 2 A @ 30 VAC/VDC 1 Slot 15 mA 75 mA
4100-3202 Four DPDT relays, 10 A @ 250 VAC 2 Slots 15 mA 175 mA
4100-3203 Eight SPDT relays, 3 A @ 30 VAC/VDC
These modules are nonpower-limited
and wiring must be routed away from
power-limited wiring.
1 Slot 25 mA 280 mA
Current Calculation Notes:
1. To determine total supervisory current, add currents of modules in panel to base system value and all external loads powered
by panel power supplies.
2. To determine total alarm current, add currents of modules in panel to base system alarm current and add all panel NAC loads
and all external loads powered from panel power supplies.
120 VAC Models 4 A maximum @ 102 to 132 VAC, 60 Hz
Input Power [System (SPS); Expansion
(XPS); Remote (RPS); TrueAlert Power
Supplies (TPS); and 100 W amplifiers]
220-240 VAC Models
2 A maximum @ 204 to 264 VAC, 50/60 Hz;
separate taps for 220/230/240 VAC
Total Power Supply
Output Rating
9 A total @ nominal 28 VDC, including module currents
and auxiliary power outputs
Auxiliary Power Tap 2 A maximum @ nominal 28 VDC
Power Supply
Output Ratings
(System, Expansion,
and Remote Power
Supplies)
NACs Programmed
for Auxiliary Power
2 A maximum per NAC, 5 A maximum @ nominal 28 VDC
Output switches to
battery backup
during mains AC
failure or brownout
conditions
Battery capacity range
6.2 Ah to 50 Ah; selectable via programming for batteries below 18 Ah; the SPS is
UL listed for up to 110 Ah battery charging for remotely located batteries
Battery Charger
(System and Remote
Power Supply)
Charger characteristics
and performance
Temperature compensated, dual rate, recharges depleted batteries within 48
hours per UL Standard 864, to 70% capacity in 12 hours per ULC Standard S527
Operating Temp. Range 32° to 120°F (0° to 49° C)
Environmental
O
p
eratin
g
Humidit
y
Ran
g
e U
p
to 93% RH, non-condensin
g
@
90° F
(
32° C
)
maximum
MINIPLEX Transponder Product Selection
General Specifications
