Simplex 4100U Operation Reference

Tyco is a registered trademark of Tyco International Services GMBH and is used under license. Simplex, IDNet, MINIPLEX, InfoAlarm, and the Simplex logo are trademarks of
Tyco International Ltd. and its affiliates and are used under license. National Electrical Code and NFPA are trademarks of the National Fire Protection Association.
Tyco Safety Products Westminster • Westminster, MA • 01441-0001 • USA S4100-0045-4 11/2007
www.tycosafetyproducts-usa-wm.com
© 2007 Tyco Safety Products Westminster. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
General Display Specifications
Dot Matrix Size 320 x 240
Active Display
Area
4.53” W x 3.4” H (115 mm x 86 mm), includes header, footer, and softkey
area; 5.66” diagonal measurement (144 mm)
Characters Up to 854 characters total using standard ASCII character font
Size Reference
Designation QVGA; one quarter of standard VGA (Video Graphics Array) display
Display Polarizer Type Transflective with rear backlight
Display Adjustment Contrast adjustment is located on the controller module
Backlight
White LEDs with intensity adjustment and selectable AC power fail operation;
intensity adjustment is located on the controller module
Backlighting Operation Options
On continuously; Off with AC power fail until a switch is pushed; selectable
timeout without switch activity
Control Panel Mounted InfoAlarm Command Center Current Requirements
Supervisory 447 mA @ 24 VDC
Master Controllers (4100-9114, -9115,
-9116, -9212, -9213, -9222)
Alarm 542 mA @ 24 VDC; backlight and tone-alert on
Supervisory 782 mA @ 24 VDC
Redundant CPUs
(4100-9122, -9222)
Alarm 964 mA @ 24 VDC; backlight and tone-alert on
Supervisory 492 mA @ 24 VDC
Network Display Units, Non-Voice
(4100-9151, -9153, -9154, -9243, -9245)
Alarm 547 mA @ 24 VDC; backlight and tone-alert on
Supervisory 912 mA @ 24 VDC
Network Display Units, Voice
(4100-9152, -9155, -9156, -9244, -9246)
Alarm 989 mA @ 24 VDC; backlight and tone-alert on
4100-7153 & -7155 for 4100U add 82 mA supervisory; add 127 mA for alarm
Upgrade Kits
4100-7154 & -7156 for Legacy 4100+
add 235 mA supervisory; add 280 mA for alarm
Panel currents only
are shown, add
external device
loading per system
requirements
Remote Annunciators with InfoAlarm Command Center, Powered from Control Panel
Voltage 19 to 33 VDC (24 VDC nominal), system supplied; requires separate wiring
Supervisory 186 mA @ 24 VDC
Current
Alarm 214 mA @ 24 VDC; backlight and tone-alert on
Mounting Details; Stand-Alone Cabinet Models See page 6 for reference illustration
Type
RUI (Remote Unit Interface) external annunciator communications line SLC
(signaling line circuit)
Capacity
Up to 31 total remote RUI devices, including up to 10 InfoAlarm Command
Center devices
4100U Capacity,
RUI Output
RUI Device
Reference List
4100U: InfoAlarm Command Center, Remote Annunciators, MINIPLEX
Transponders; 4603-9101 LCD Annunciator, 4602-9101 Status Command
Unit (SCU), and 4602-9102 Remote Command Unit (RCU); refer to data
sheet S4100-0031 for additional 4100U RUI information
Data Single twisted, shielded pair, 18 AWG (0.82 mm
2
)
Power 18 to 12 AWG (0.82 mm
2
to 3.31 mm
2
) wires for 24 VDC system power
Wiring Requirements
Earth
A dedicated earth ground connection to the electrical box is required for
proper ESD and EMI protection; wire in accordance with NFPA 70 (National
Electrical Code
®
) Article 250
Custom Point Detail Messages
Message Location Details
Select “more info” softkey when investigating point detail and scroll to the
bottom of the information; typical messages might include contact details
(phone numbers, pager numbers, etc.) and other contact or reference
information
Number of Messages Up to 50
Character Details
120 characters; visible characters = 116; (lines 1 and 2 require one carriage
return character and one line feed character)
Message Size
Line Details
3 lines total; 40 characters maximum per line; line 3 may be limited to 36
visible characters depending on characters in lines 1 and 2
Operating Temperature 32° to 120°F (0° to 49° C)
Environmental
Operating Humidity Up to 93% RH, non-condensing @ 90° F (32° C) maximum
Specifications

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
