6 - 67
6 General Repair
6D Hood, Dash, & Grill Repair
Figure D–16. Remove Cable From Throttle Lever
16. See Figure D–16 Note the engagement of the cable
end in the throttle lever, and remove the throttle cable
from the hole in the throttle lever. Position the throttle
cable out of the way so that it does not interfere with
shift lever and lift lever service .
17. See Figure D–17. On models equipped with a choke,
loosen the choke cable clamp on the engine using a
screwdriver. Note the position of the choke lever and
the engagement of the cable end in the choke lever.
Throttle Lever
Figure D–17. Remove Choke Cable From Engine
