7 - 29
7 Transmission Repair
7C Hydro-Gear 216-3010L
Item Qty. Description
1. 1 KEY, Hi-Pro, 3/16 x 5/8
2. 2 PIN, Brake Actuating
3. 1 DISC, Brake
4. 1 PLATE, PUCK
5. 2 PUCK, Brake
6. 1 BOLT, Nyloc, Gr. 5, 1/4-20 x 1
7. 1 WASHER, Flat
8. 1 PLUG, Straight Thread
9. 2 WASHER, 7/8 x x7/16 x
10. 1 ARM-BRAKE
11. 1 NUT, Castle, 7/16
12. 2 SPRING
13. 1 SPRING, Extension
14. 1 RING, Wire Retaining
15. 1 FITTING/O-RING ASSY.
16. 1 HOUSING ASSY., RH
17.* 2 OIL SEAL, 63/64 x 1-1/2 x 1/4
18*. 1 QUAD RING
19*. 1 GASKET, Filter Base
20. 1 BASE, Filter Assy.
21. 1 PINION ASSY.
22. 1 BRAKE SHAFT ASSY.
23. 2 AXLE MOUNTING HORN ASSY.
24. 2 WASHER, 1 x 1-5/8 x 5/64
25. 2 WASHER, 1 x 2-1/16 x 3/32
26. 1 INPUT ASSY.
27. 2 BEARING, Retainer
28.* 2 QUAD RING
29. 1 BRAKE YOKE ASSY.
30. 1 SPACER
31. 1 BOLT, 1/4-20 x 2
32. 1 WASHER, Wave
33. 2 PIN, Dowel
34. 1 GEAR, Reduction, 14T-38T
35. 1 FINAL DRIVE PINION ASSY.
Item Qty. Description
36. 1 JACK SHAFT
37.* 1 O-RING
38. 2 WASHER, 5/8 I.D. X 1-5/32 O.D.
39. 1 WASHER, 7/8 I.D. X 1-1/2 O.D.
40. 2 BOLT, Hex Hd., 5/16-18 x 3-1/2
41. 4 LOCKNUT, Hex, 5/16-18
42. 11 BOLT, Hex, Gr. 5, 5/16-18 x 1/2
43. 7 CAPSCREW, Hex, Gr. 5, 5/16-18 x 1
44.** 1 WASHER, Differential, 1/2
45. 1 BOLT, Shoulder
46. 1 ARM, Freewheel Actuating
47.* 2 SEAL, Oil, 5/8 x 1 x 1/4
48. 1 BOLT, Hex, Gr. 5, 5/16-18 x 1-3/4
49. 3 BOLT, Hex, Gr. 5, 5/16-18 x 1/2
50. 2 FITTING, 1/2, Beaded, 90o, 9/16, SAE
51. 1 FITTING, 1/2, Straight, 9/16, SAE
52. 1 FITTING, 1/2, Beaded, 90o, 7/8, SAE
53. 2 HOSE, 1/2”, 8-3/4” Long
54. 1 FILTER, Spin-on, Bypass
55. 1 WASHER, 11/32 I.D. x 9/16 O.D.
56. 1 WASHER
57.* 2 O-RING
58. 4 PINCH CLAMP
59. 1 HOUSING ASSY., LH
60. 1 HYDRO PUMP
(See next pg. for service parts)
61. 1 DIFFERENTIAL ASSY.
62. 1 BRACKET
63. 1 COTTER PIN
64. 2 CAPSCREW, 1/4-20 x 1
* These parts can be ordered as Seal Kit.
** Used on early models only. Not required with later style
Differential Assy. (Ref. No. 61).
