5 Electrical Troubleshooting
Main Wiring Harness
1 1 COVER, Terminal
2 1 CABLE, Battery-to-Solenoid
3 1 HOSE, Battery, Drain
4 1 WIRE ASSY.
5 1 CIRCUIT BREAKER
6 1 CABLE, Solenoid-to-Starter
7 1 HOLD DOWN, Battery
8 5 BULB, Indicator Light
9 1 BOOT, Insulator
10 1 BATTERY, 39 Amp (Power Max)
11 1 SOLENOID
12 1 IGNITION SWITCH (Incl. Ref. No. 27, 28, 39)
13 1 SWITCH, Transmission, Neutral Start
14 1 SWITCH, Headlight
15 1 MODULE
16 1 TRAY, Battery
17 1 COVER, Key Switch
18 2 NUT, Plastic, 1/4-20
19 1 VENT, Battery
20 1 STRAP, Wire Retainer
21 2 ROD, Battery Hold Down
22 1 SWITCH, Lift
23 1 HOUR METER
24 1 SWITCH
25 1 CABLE, Battery-to-Ground
26 1 SWITCH, PTO, Electric Clutch
27 2 KEY, Ignition
28 1 ADAPTER, Nut
29 1 HARNESS, Wiring
30 1 HARNESS, Upper
31 2 NUT, Hex, Full, 1/4-20
32 2 LOCKWASHER, 1/4
33 2 LOCKWASHER, 5/16
34 2 NUT, Hex, 5/16-24
35 4 WASHER, Plain, 9/32
36 2 CAPSCREW, Hex, 1/4-20 x 3/4
37 2 SCREW, Plastite, 1/4-20 x 5/8
38 7 SCREW, Plastite, #8-16 x 1/2
39 1 LOCKWASHER, Internal Tooth
REF.
NO. QTY. DESCRIPTION
MAIN WIRING HARNESS
