Simplicity 6100 Series User Manual

mower, the hitch rods to lower the
front of the mower.
9. Replace pins through clevises and rear
suspension arm and recheck measure¬
ments. When the mower is level re¬
place and spread cotter pins, and
tighten nuts against clevises.
SEAT ADJUSTMENT
NOTE
If the seat is equipped with springs, see
“Seat Adjustment with Spring Sus¬
pension.”
The seat may be moved forward or back¬
ward to suit different size operators. To
move the seat proceed as follows: j
1. Raise the seat deck by lifting the latch
on the left side of the seat (see figure
43).
2. Loosen the two handles (figure 43)
holding the seat.
3. Move the seat forward or backward as
desired.
4. Tighten the handles to hold the seat in
place.
Figure 43. Seat Adjustment
SEA^T^TdJuSTMEW^ITH SPRfNG
SUSPENSION
1. Lift up the seat from the rear (figun
43).
2. Loosen the four nuts under the sea
and slide the seat forward or back
Tighten the nuts firmly.
3. The springs can be moved to differen
holes in the deck for maximum ridinj
Lomfiiii \ lialiterperson will want t(
mi)\e ilu. ^ptlllgs more forward.
Figure 43. Seat With Spring Suspen
: sion
