23
en
A
E
D
B
F
D
I
J
G
H
Figure 10
Standard Oil Drain Plug
1. Remove the oil drain plug (B, Figure 10). Drain the oil
into an approved container.
2. After the oil has drained, install and tighten the oil
drain plug.
Optional Quick Oil Drain
1. Disconnect the oil drain hose (G, Figure 10) from the
side of the engine.
2. Turn and remove the oil drain cap (H). Carefully lower
the quick oil drain (I) into an approved container (J).
3. After the oil has drained, install the oil drain cap. At-
tach the oil drain hose to the side of the engine.
Changing the Oil
Used oil is a hazardous waste product and must be dis-
posed of properly. Do not discard with household waste.
Check with your local authorities, service center, or dealer
for safe disposal/recycling facilities.
Remove Oil
plug wire (A, Figure 10) and keep it away from the
spark plug.
2. Remove the dipstick (D).
To Next Page
