Servicing the Air Filter
-
1. Remove the cover (A, Figure 12).
B
3. Remove the pre-cleaner (C), if equipped, from the
5. Wash the pre-cleaner in liquid detergent and water.
Then allow it to thoroughly air dry. Do not oil the pre-
cleaner.
D) and push
8. Install the cover.
1. Park the tractor on a hard, level surface such as a
remove the key, and apply the parking brake.
2. Place the mower in the lowest cutting position using
the cutting height adjustment switch (see Features and
Controls).
3. Pull the idler pulley lever (A, Figure 13) to release belt
tension. Remove belt (B) from PTO pulley (C).
4. Remove cotter pin (A, Figure 14) and washer (B) that
attach mower support (C) to tractor frame. Repeat for
other side.
5. Turn the wheels straight ahead. Remove hitch pin and
safety clip that attach mower hanger to tractor hitch
bracket (see 1-3, Figure 15).
7. Turn wheels full left, and slide mower deck out from
under the right of the tractor.
Removing the Mower Deck
WARNING
Engage the parking brake, disengage PTO, stop en-
gine, and remove key before attempting to remove
the mower deck.
