QUICK START REFERENCE FOR TYPICAL
CONTROL INSTRUMENT FEATURES
This section outlines the most commonly used features of the Hawk 3 controller
and functions as a quick start guide. Please refer to the table of contents to find
in-depth information or advanced features.
Installation and Wiring
See Section 1 in this manual for specific wiring and installation information per-
taining to user’s specific unit. With only the power supply wired, the Hawk 3 can
be programmed before installation. The Hawk 3 features non-volatile memory;
programming information will not be lost due to power loss or when changing
meter’s location.
Programming
Many of the advanced features of the Hawk 3 respond to, and interact with, each
other. When programming the Hawk 3 it is important that the proper order is fol-
lowed when setting up features. The following is the recommended order.
1. Decimal Point
2. Linearization (AKA Scaling)
3. Set Point/Relay Control (if applicable)
4. Analog output or other applicable controls.
Basic Key Operation (for Programming)
1. enters the main programming menu, backs out of submenus (one level at a
time) and returns to run mode from the main menu. Exiting the programming
menu in this manner assures that all changes will be saved.
also moves
the cursor to the left.
2.
scrolls through menus and changes parameters.
3. RES opens submenus, moves a blinking parameter into edit mode and allows
editing.
Decimal Point
Using the 3-1/2 digital Hawk 3 as an example, the decimal point can be placed
in any one of 5 locations without affecting the number. For example, 10 volts will
display as 10.00. This display can be changed to get 100.0. Keep in mind that the
decimal point is still needed for some applications.
1. Press
to enter the programming mode.
2. Scroll
until “G&W/”(display control) shows. Press
3. When “G3” and “
” flashes, press
.
4. “
” is now a fixed display. Use or to move the decimal point as neces-
sary. Press
5. Use
to save changes.
5
.
.
