b. Latch: This parameter will actuate the given relay. To reset manually,
press .
i. The display will flash between “/W&+ ” and a number. Press ent .
ii. Enter the amount of delay desired before the relay actuates. (0-60
Seconds) Press ENT .
c. Hysterisis: This is the percentage above or below the setpoint where
the
relay will actuate.
i. The display will show “+B/R ” and a number. Press .
ii. Enter the % of hysterisis (0-29.9%) falling Edge, Press .
iii. The display will show “+B+L ” and a number. Press .
iv. Enter the % of hysterisis (0-29.9%) rising Edge. Press .
6. To set alarm to “Hi”, “Lo” or “Off ”, press when display flashes
Choose “Hi”, “Lo” or “Off” and press .
7. Next choose the state of the relay to be Normally Energized “Q(” or
De-Ener-gized “QG ”. When display flashes press . Choose desired state
Press to return to main menu.
8. Set SP2, SP3 and SP4 as necessary and save changes.
7
