Simpson H335 User Manual

RS-485 Specications (only available on H345)
2 wire / Half duplex, Baud rate: 9600 baud, 1ms delay per character, 32 Nodes Maximum on Bus. Opti-
cally and magnetically isolated for ground loop elimination
MECHANICAL
Bezel 3.92” x 2.0” x 0.52” (99.8mm x 51.9mm x 132mm)
Depth 3.24” (82.3mm) behind panel
Panel cutout 3.62” x 1.77” (92mm x 45mm) 1/8 DIN
Weight 10 oz. (283.5 g)
Cover NEMA 4X Rated front panel
ELECTRICAL
Accuracy Listed as % of reading at 25°C. Add 100ppm/°C to compensate for drift.
Tested at 50Hz, include +/-1 count for every 100Hz above 50 Hz
Transient Overvoltage Installation Category III, Pollution Degree 2
Analog Output
Sampling Rate = 100 mSec. Reaction TLPHWR)XOO6FDOH ȝ6HF
Table 1 - 1
Input Board
Type Range
Resolution
4-1/2
Resolution
3-1/2
Input
Impedance Overload
Accuracy
4-1/2
Accuracy
3-1/2
DC
Voltage
Vm002 10 ȝV .1 mV 1M  5 DCV ± .05% of reading ± 1 count ± .1% of reading ± 1 count
V2 .1 mV 1 mV 1M  5 DCV ± .05% of reading ± 1 count ± .1% of reading ± 1 count
20 V 1 mV 10 mV 1M  300 DCV ± .05% of reading ± 1 count ± .1% of reading ± 1 count
200 V 10 mV .1 V 1M  300 DCV ± .05% of reading ± 1 count ± .1% of reading ± 1 count
600 V .1 V 1 V 1M  1K DCV ± .1% of reading ± 1 count ± .2% of reading ± 1 count
Table 1 - 3
Input Board
Type Range
Resolution
4-1/2
Resolution
3-1/2
Input
Impedance Overload
Accuracy
4-1/2
Accuracy
3-1/2
AC Voltage
(Same for
TRMS
* @ 60 Hz)
Vm002 10 ȝV .1 mV 200K  5 DCV ± .05% of reading ± 1 count ± .1% of reading ± 1 count
V2 .1 mV 1 mV 200K  5 DCV ± .05% of reading ± 1 count ± .1% of reading ± 1 count
20 V 1 mV 10 mV 1M  300 DCV ± .05% of reading ± 1 count ± .1% of reading ± 1 count
200 V 10 mV .1 V 1M  300 DCV ± .05% of reading ± 1 count ± .1% of reading ± 1 count
600 V .1 V 1 V 1M  1K DCV ± .1% of reading ± 1 count ± .2% of reading ± 1 count
Table 1 - 2
Input Board
Type Range
Resolution
4-1/2
Resolution
3-1/2
Input
Impedance Overload
Accuracy
4-1/2
Accuracy
3-1/2
DC
Current
200 ȝA 10 nA .1 ȝA1K  4.5 mA DC ± .05% of reading ± 1 count ± .1% of reading ± 1 count
Am2.1 ȝA1 ȝA 100  45 mA DC ± .05% of reading ± 1 count ± .1% of reading ± 1 count
20 mA 1 ȝA 10 ȝA 10  200 mA DC ± .05% of reading ± 1 count ± .1% of reading ± 1 count
200 mA 10 ȝA .1 mA 1  600 mA DC ± .05% of reading ± 1 count ± .1% of reading ± 1 count
2 A .1 mA 1 mA .013  5.5 A DC ± .2% of reading ± 1 count ± .3% of reading ± 1 count
5 A 1 mA 10 mA .013  5.5 A DC ± .2% of reading ± 1 count ± .3% of reading ± 1 count
Table 1 - 4
Input Board
Type Range
Resolution
4-1/2
Resolution
3-1/2
Input
Impedance Overload
Accuracy
4-1/2
Accuracy
3-1/2
AC Current
(Same for
TRMS
* @ 60 Hz)
200 ȝA 10 nA .1 ȝA 1K  4.5 mA DC ± .1% of reading ± 1 count ± .2% of reading ± 2 count
Am2.1 ȝA1 ȝA 100  45 mA DC ± 1% of reading ± 2 count ± .2% of reading ± 2 count
20 mA 1 ȝA 10 ȝA 10  200 mA DC ± .1% of reading ± 2 count ± .2% of reading ± 2 count
200 mA 10 ȝA .1 mA 1  600 mA DC ± .1% of reading ± 2 count ± .2% of reading ± 2 count
2 A .1 mA 1 mA .013  5.5 A DC ± .2% of reading ± 2 count ± .3% of reading ± 2 count
5 A 1 mA 10 mA .013  5.5 A DC ± .2% of reading ± 2 count ± .3% of reading ± 2 count
9

Simpson H335 Specifications

General

Brand	Simpson
Model	H335
Category	Controller
Language	English
