3
SECTION A: Knowing your washing machine
PART OF THE MACHINE
SAVING WATER AND ENERGY
This booklet talks about different parts of your washing machine.
The main ones you need to know are shown on the diagrams below.
This washing machine features water and energy saving options.
To save energy, the wash time can be shortened for a load of less dirty clothes by pressing the
Wash Choice button to select a shorter wash time option eg. Light & Fast.
The washing machine is energy efficient and most water efficient when used with a full
load of clothes and with ECO RINSE selected. You should use ECO RINSE (where available)
instead of Deep Rinse to reduce the amount of water used for rinsing clothes.
Your machine is most water efficient when ECO RINSE is used as the rinse option.
Each time you switch on your washing machine, Eco Rinse is selected for you to help you save
money and to reduce the impact on the environment. You can select the traditional Deep Rinse
option for your first wash load if you wish. See page 13.
The difference between Deep rinse and Eco rinse is explained on the next page.
Fabric softener dispenser
Outlet Hose / Drain Hose
Wash bowl
Agitator
Lint filter
Control Panel
Lid
See installation
instructions to
fit & position
drain hose
