Simrad GO XSE Quick Guides

|
5
GO XSE | Quick Guide - EN
Application pages
Each application connected to the system is presented on panels. All application
pages are accessed from the home page.
4
3
1
5
8
7
2
6
No. Item
1 Application panel
2 Instrument bar
3 System controls dialog
4 Status bar
5 Dialog
6 Control Bar
7 Alarm message
8 Menu
Adjust panel size
Change the panel size for an active split page:
1. Activate the System controls dialog
2. Select the adjust splits option in the dialog
3. Adjust the panel size by dragging the adjustment icon
4. Confirm your changes by tapping one of the panels or selecting the save option
in the menu

Simrad GO XSE Specifications

General

GPS	Yes
Chartplotter	Yes
NMEA 2000	Yes
Wi-Fi	Yes
Bluetooth	Yes
Waterproof Rating	IPX7
Operating Voltage	12V DC
Sonar	Yes (built-in)
Cartography	C-MAP, Navionics
Mounting Type	Bracket or Flush Mount
Screen Size	7-inch, 9-inch
Screen Resolution	800 x 480 pixels
