Simrad is42 Installation Guide

Mounting
System wiring example
Simrad B&G
2
1
1 NMEA 2000 Backbone
2 Micro-C Drop cable
3 Micro-C Power cable
4 Micro-C T-Joiners
5 Micro-C Terminator, 120 Ohm
6 Drive cable
T
T
12/24V DC
12V DC
AUTOPILOT
COMPASS
SPEED / DEPTH
SENSOR
DRIVE UNIT
RUDDER
FEEDBACK
6
5
4
3
AP44
AUTOPILOT
CONTROLLER
OP12
AUTOPILOT
CONTROLLER
Power
NMEA 2000 Backbone
Micro-C Drop cable
Rudder Drive cable
IS42
INSTRUMENT
DISPLAY
MASTHEAD
UNIT
GPS
SENSOR
2
1
1 NMEA 2000 Backbone
2 Micro-C Drop cable
3 Micro-C Power cable
4 Micro-C T-Joiners
5 Micro-C Terminator, 120 Ohm
6 Drive cable
T
T
12/24V DC
12V DC
AUTOPILOT
COMPASS
SPEED / DEPTH
SENSOR
GPS
SENSOR
DRIVE UNIT
RUDDER
FEEDBACK
6
5
4
3
Triton²
AUTOPILOT
CONTROLLER
Power
NMEA 2000 Backbone
Micro-C Drop cable
Rudder Drive cable
Triton²
INSTRUMENT
DISPLAY
MASTHEAD
UNIT
STEP 1 STEP 2 STEP 3 STEP 4 STEP 5
* Caution: Maximum driver head width
5.0 mm (0.19”)

Simrad is42 Specifications

General

Brand	Simrad
Model	is42
Category	Autopilot System
Language	English
