Simrad NSE12 Quick Reference Guide

*988-0175-04A*
Creating a route
Press the 1 PLOT key and select the new route option
Use the arrow keys to move the cursor to the position for the 2
¿UVWZD\SRLQW
&RQ¿UPWKHSRVLWLRQE\SUHVVLQJWKHURWDU\NQRE3
Move the cursor to the position for the next waypoints, and 4
FRQ¿UPWKHSRVLWLRQE\SUHVVLQJWKHURWDU\NQRE again
Repeat moving the cursor and pressing the rotary knob until 5
all waypoints in the route are created
Press the 6
MENU key to save the route
The Edit route mode and route information is indicated on top of the panel
until the route is saved.
You can also create a route from the Routes table or by converting a track to a route.
Refer to the Utilities pages in the NSE8/NSE12 Operator manual.
Navigate a route
You can navigate towards a waypoint or along a predefined route. As
soon as a route or a destination point is selected, you can switch to the
Steer panel to see navigation info.
l
M EE
PLOT GO TO
MARK VESSEL
NAV
