Simrad NSS evo2 Quick Start Guide

Application pages
Activate an application page by:
• tapping the application button (full page panel), by
• tapping a favorites button, or by
• pressing and holding an application button to select a predefined split page.
32
1
1
2
3
Status panel
Application panel
Instrument bar
Adjust panel size
You can adjust the panel sizes in a split page.
1. Tap the adjust split button in the System Control dialog to show the resize icon
2. Drag the resize icon to set preferred panel size
3. Save the changes by tapping the screen.
Favorite page overlay
Display the favorite buttons as a pop-up on any page by pressing and holding the
Home key.
2 s

Simrad NSS evo2 Specifications

General

Display Size	7", 9", 12", 16"
Radar Support	Yes
Chartplotter	Yes
Autopilot Compatible	Yes
NMEA 0183	Yes
Video Input	Yes
Operating Temperature	-15°C to +55°C (5°F to 131°F)
