SPECIFICATIONS
Display
Resolution 7” unit
9” unit
12” unit
1024 x 600 px
1280 x 720 px
1280 x 800 px
Brightness >1200 nits
Touch screen Full touch screen (multi-touch)
Viewing angles in degrees (typical value at contrast
ratio = 10)
85° (top, bottom, left, and right)
Electrical
Supply voltage 12 V DC (10 - 17 V DC min - max)
Recommended fuse rating 7” unit
9” and 12” unit
2 A
3 A
Protection Protected against reverse polarity
and temporary over-voltage to 18 V
Power consumption - max 7” unit
9” unit
12” unit
11.5 W (830 mA at 13.8 V)
18.8 W (1360 mA at 13.8 V)
29.7 W (2150 mA at 13.8 V)
Environmental
Operating temperature range -15°C to 55°C (5°F to 131°F)
Storage temperature -20°C to 60°C (-4°F to 140°F)
Waterproof rating IPx6 and IPx7
Humidity IEC 60945 Damp heat 66°C (150°F) at
95% relative (18 hr)
Shock and vibration 100 000 cycles of 20 G
Interface and connectivity
GPS 10 Hz high speed update (internal)
WASS, MSAS, EGNOS, GLONASS
Bluetooth Bluetooth 4.0 with support for
Bluetooth Classic
Wi-Fi IEEE 802.11b/g/n
Ethernet/Radar 1 port (5-pin connector)
Echosounder 1 port (9-pin connector)
NMEA 2000 1 port (Micro-C)
