Simrad NSX Installation Manual

22
DIMENSIONAL DRAWINGS
7” unit
220.0 mm
(8.66 in)
1
95.0
mm
(
7.68 in
)
123.0 mm
(4.84 in)
145.9 mm
(5.74 in)
62.0 mm
(2.44 in)
71.5
m
m
(
2.82 in
)
107.0 mm
(4.21 in)
8.0
mm
(
0.32 in
)
9” unit
263.0 mm
(10.35 in)
239.0
mm
(
9.40 in
)
148.5 mm
(5.85 in)
172.6 mm
(6.80 in)
65.3 mm
(2.57 in)
7
2.6
m
m
(
2.86 in
)
109.9 mm
(4.33 in)
8.0
mm
(
0.32 in
)

Simrad NSX Specifications

General

Wi-Fi	Yes
Bluetooth	Yes
Touchscreen	Yes
GPS	Yes
NMEA 2000	Yes
Cartography	C-MAP, Navionics
Waterproof Rating	IPX6
Operating Temperature	-15°C to +55°C
