15
WIRING
Wiring guidelines
Don’t:
• Make sharp bends in the cables.
• Run cables in a way that allows water to ow down into the connectors.
• Run the data cables adjacent to radar, transmitter, or large/high current carrying cables or
high frequency signal cables.
• Run cables so they interfere with mechanical systems.
• Run cables over sharp edges or burrs.
Do:
• Make drip and service loops.
• Use cable-ties on all cables to keep them secure.
• Solder/crimp and insulate all wiring connections if extending or shortening the cables.
Extending cables should be done with suitable crimp connectors or solder and heat shrink.
Keep joins as high as possible to minimize the possibility of water immersion.
• Leave room adjacent to connectors to ease plugging and unplugging of cables.
⚠Warning: Before starting the installation, turn the electrical power o. If power
is left on or turned on during the installation, re, electrical shock, or other serious
injury may occur. Be sure that the voltage of the power supply is compatible with the
unit.
⚠Warning: The positive supply wire (red) should always be connected to (+) DC
with a fuse or a circuit breaker (closest available to fuse rating). For the recommended
fuse rating, refer to the Specications section of this manual.
