Icons
GNSS mode icons
GPS satellites
GPS + GLONASS satellites
GPS and DGPS icons
Satisfactory autonomous GPS position
No position fix
Correction is not available
SBAS signal correction applied to augment signal
Differentially corrected signal (RTCM corrections)
The number of highlighted bars indicate the signal strength. The
more highlighted bars, the stronger signal.
RAIM status indicators
Icon Status Description
Safe
Any position error is within the specified
limit
Caution
No RAIM, the system is receiving signals
from less than five GPS satellites
Unsafe
The statistical position error exceeds the
specified limit.
