4 |
Spare part
20193454 Transmitter link
Technical specications
¼ Note: The most up-to-date specications list is available at
www.simrad-yachting.com
Physical
Dimensions See gure
Weight 0.5 kg (1.1 lbs.)
Material Arnite T06 200 PBT
Compass safe distance 1.0 m (3.1 ft.)
Mounting Horizontal, vertical or upside down
Cable 15 m (49 feet) with connector
Transmitter link Stainless 345 mm (13.6”) with 2 ball joints
Electrical
Supply voltage 5 V DC
Power consumption 2.5 mW
Environmental
Operating temperature -25 to +55 °C (–13 to +130 °F)
Storage temperature -30 to +70 °C (–22 to + 158 °F)
Waterproof rating IP56
Interface
Rudder angle +/-120 degrees
Output signal 0 - 5 V DC
Resistance value 10 K ohms
Accuracy +/-0.25° within +/-5°, otherwise +/-0.5°
Repeatability +/-0.1°
*988-12045-001*
