StructureScan LSS-1 Installation manual | 9
If the LSS-1 is connected directly to the vessel’s battery,
the module will continue to draw power even when it
is not in operation. It is recommended that the yellow
power cable wire be tted with an optional on/off switch,
allowing the LSS-1 to be powered off when not in use.
Reference Description
A Ethernet cable
B StructureScan Transducer cable
C StructureScan Y-cable (option)
For part numbers, see Spare parts and assessories
on page 11.
A
A
B
B
B
orC
PWR
LTWLTW
LTW LTW
LTW LTW
