4 | StructureScan LSS-1 Installation manual
Introduction
This document describes how to install the
StructureScan™ LSS-1 and connect the unit to
transducers and display units.
Separate installation instruction for transducers are
included with the transducer package.
Parts included in package
For spare parts and part numbers, see Parts list page
11.
Item No. Description.
1 LSS-1 Black box module
1 4 pin power cable
1 Fuse, 3A Automotive Type
1 Fuse holder
2 Yellow Ethernet caps
1 Close end crimp connector
4 Phillips stainless steal screws (#8)
1 Warranty
1 This manual
