No. Name No. Name
1
Interface of health function
neutral wire
10 WIFI terminal
2 Neutral wire terminal 11 Wired controller terminal
3 Motor terminal 12 Interface of display board
4
Interface of health function
live wire
13 Jumper cap
5 Auto button 14
Communication terminal for
indoor unit and outdoor unit
6 Up&down swing terminal 15
Terminal of live wire used for
supplying power for outdoor unit
7 Interface of Motor feedback 16 Live wire terminal
8 Left&right swing terminal 17 Fuse
9 Terminal of temperature sensor 18 Interface of ultraviolet clean
19 Interface of gate control
SIH-12BIK
