echnical Information
Service Manual
Model
SIH + SOH-09BIK2 SIH + SOH-12BIK2
Power
Supply
Rated Voltage
V~
220-240 220-240
Rated Frequency
Hz
50 50
Phases
1 1
Power Supply Mode
Outdoor Outdoor
Cooling Capacity
W
2700
3200
Heating Capacity
W
2800
3400
Cooling Power Input
W
725
933
Heating Power Input
W
685 872
Cooling Current Input
A
3.45
4.14
Heating Current Input
A
3.19 3.87
Rated Input
W
1500 1500
Rated Cooling Current
A
6 6.5
Rated Heating Current
A
7.5 7.5
Air Flow Volume
m
3
/h
550/520/480/400/340/310/280 680/620/560/490/450/420/390
Dehumidifying Volume
L/h 0.8
1.4
EER
W/W
3.72 3.43
COP W/W 4.09
3.9
SEER 6.8 6.5
HSPF / /
Application Area
m
2
10-16 15-22
Indoor Unit
Model
SIH-09BIK SIH-12BIK
Fan Type
Cross-ow Cross-ow
Fan Diameter Length(DXL)
mm
Ф93X580 Ф98X630
Cooling Speed
r/min
1300/1200/1120/1050/920/800/750 1350/1200/1100/1000/920/850/800
Heating Speed
r/min
1300/1200/1120/1050/950/850/800 1300/1200/1120/1050/980/900/850
Fan Motor Power Output
W
20 20
Fan Motor RLA
A
0.22
0.3
Fan Motor Capacitor μF
1
1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter
mm
Ф5 Ф5
Evaporator Row-n Gap
mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW)
mm
584X22.8X266.7
634X22.8X304.8
Swing Motor Model
MP24AN
MP24EB/MP24HF
Swing Motor Power Output
W
1.5 1.5/1.5
Fuse Current
A
3.15 3.15
Sound Pressure Level
dB (A)
Cooling: 40/37/35/33/29/26/21
Heating: 40/37/35/33/30/26/24
Cooling: 42/39/36/35/32/29/23
Heating: 42/39/36/34/32/28/26
Sound Power Level
dB (A)
Cooling: 56/49/47/45/41/37/34
Heating: 55/49/47/45/42/38/35
Cooling: 57/52/49/48/44/41/37
Heating: 56/52/49/47/45/41/38
Dimension (WXHXD)
mm
770X251X190 849X289X215
Dimension of Carton Box
(LXWXH)
mm
817X308/251 897X341X268
Dimension of Package (LXWXH)
mm
822X324X262 902X357X279
Net Weight kg
8 10.5
Gross Weight kg
9.5 12.5
2.1 Specication Sheet
2. Specications
To Next Page
